盘点那些常见排针排母连接器的型号
- 发布日期 : 2019-04-29 16:22
- 点击率 : 176
排针排母广泛应用于计算机主板,各种移动存储盘,无绳电话,对讲机,可视电话,程控交换机,车载系统,DVD,LCM\LED显示屏块,仪器仪表,电子玩具,医疗设备及光电产品等诸多领域。
现在的行业里，排针排母几乎每种电子消费产品都拥有标准型A、B或迷你型的USB接口，也有相应的USB接口连接器。在汽车中使用这种接口的一个不可忽视的问题。下面我们就一起来看看排针排母有哪些型号吧。
2.54mm排针系列：
2.54mm单排针,单排双塑,180度,H=1.5/2.0/2.5mm
2.54mm双排针,双排双塑,180度,H=1.5/2.0/2.5mm
2.54mm单/双排弱,90度,H=1.5/2.0/2.5mm
2.54mm单/双排针,SMT,H=1.5/2.0/2.5mm
2.54mm单排双塑,双排双塑,SMT,H=1.5/2.0/2.5mm
2.54mm三排针,90/180度,H=2.5mm
2.54mm单/双排针,打K,H=1.5/2.0/2.5mm
2.54mm双排针,90/180度,H=4.3mm
2.54mm双排针,90/180度,H=7.4mm
2.54mm双排针,双塑,90度,塑宽=9.7mm,H=2.54mm
2.00mm排针系列：
2.00mm单排针,单排双塑,180度,H=1.0/1.5/2.0mm
2.00mm双排针,双排双塑,180度,H=1.0/1.5/2.0mm
2.00mm单/双排针,90度,H=1.0/1.5/2.0mm
2.00mm单排双塑,双排双塑,90度,H=1.0/1.5/2.0mm
2.00mm单/双排针,SMT,H=1.0/1.5/2.0mm
2.00mm单/双排针,打K,H=1.0/1.5/2.0mm
2.00mm双排针,180度,90度,H=4.0mm
2.00mm三排针,180度,H=2.0mm
2.00mm四排针,180度,H=2.0mm
1.27mm排针系列：
1.27mm单排针,单排双塑,180度,H=1.0/1.5/1.7/2.0/2.5mm
1.27mm双排针,双排双塑,180度,H=1.0/1.5/2.0/2.5mm
1.27mm单/双排针,90度,H=1.0/1.5/2.0/2.5mm
1.27mm单/双排针,SMT,H=1.0/1.5/1.6/2.0/2.5mm
1.27mm单排双塑,双排双塑,SMT,H=1.0/1.5/2.0/2.5mm
1.27mm单排双塑,双排双塑,90度,H=1.0/1.5/1.6/2.0/2.5mm
1.00mm排针系列：
1.00mm单排针,单排双塑,180度,H=1.0/1.5mm
1.00mm双排针,双排双塑,180度,H=1.0/1.5mm
1.00mm单排双塑,SMT,H=1.0/1.5mm
1.00mm双排双塑,SMT,H=1.0/1.5mm
1.00mm单排针,双塑,SMT,H=1.0/1.5mm
0.80mm排针系列：
0.80mm双排针,SMT,180度,H=1.38mm
2.54mm排母系列：
2.54mm双排母,180度,U型端子,H=3.5mm
2.54mm双排母,蜈蚣脚,U型端子,H=3.5mm
2.54mm单/双排母,180度,U型端子,H=5.0mm
2.54mm单排母,90度,H=5.0mm
2.54mm单/双排母,SMT,H=5.0mm
2.54mm单/双排母,蜈蚣脚,U型端子,H=5.0mm
2.54mm单/双排母,180度,H=5.7mm
2.54mm单/双排母,90度,H=5.7mm
2.54mm单/双排母,180度,上插型,U型端子,H=6.8mm
2.54mm双排母,180度,下插型,U型端子,H=6.8mm
2.54mm单/双排母,180度,U型端子,H=7.1mm
2.54mm单/双排母,SMT,可带内柱,U型端子,H=7.1mm
2.54mm单/双排母,180度,H=8.5mm
2.54mm单/双排母,90度,H=8.5mm
2.54mm单/双排母,180度,H=8.5+2.5/8.5+5.0/8.5+7.5mm
2.54mm单/双排母,90/180度,带凸,H=8.5+2.5/8.5+5.0/8.5+7.5mm
2.54mm单/双排母,180度,U型端子,波浪型,H=8.5mm
2.54mm单/双排母,90度,U型端子,波浪型,H=8.5mm
2.54mm单/双排母,U型端子,蜈蚣脚,H=8.5mm
2.0mm排母系列：
2.00mm单排母,双排母,180度,H=2.1/4.0/4.3/4.6mm
2.00mm单/双排母,SMT,H=2.1/4.0/4.3/4.6mm
2.00mm单排母,90度,H=4.0/4.3/4.6mm
2.00mm双排母,夹板式,H=4.0/4.3/4.6mm
2.00mm单排母,90度,波浪型,H=4.0/4.3/4.6mm
2.00mm单/双排母,蜈蚣脚,H=4.0/4.3/4.6mm
2.00mm双排母,90度,单侧插,H=7.2mm
2.00mm双排母,90度,双侧插H=4.9mm
2.00mm双排母,SMT,双侧插,H=4.9mm
2.00mm单/双排母,180度,H=6.35mm
2.00mm单/双排母,90度,H=6.35mm
2.00mm双排母,SMT,H=6.35mm
1.27mm排母系列：
1.27mm单/双排母,180度,H=2.1/3.4/4.3mm
1.27mm单排母,SMT,H=2.1/3.4/4.3mm
1.27mm双排母,SMT,可带定位柱,H=2.1/3.4/4.3mm
1.27mm双排母,SMT,带外柱,H=2.1/3.4/4.3mm
1.27mm单排母,90度,H=2.1/3.4/4.3mm
1.27mm单/双排母,180度,H=4.6mm
1.27mm单/双排母,SMT,H=5.7mm
1.27×2.54双排母,180度,H=8.5mm
1.00mm排母系列：
1.00mm双排母,SMT,H=2.1mm(可带定位柱)
0.80mm排母系列：
0.80mm双排母,SMT,H=3.1mm
